Acoustic ceiling in sports facilities with Rockfon Samson sound absorbing ceiling tiles

Rockfon® Samson™

Highly impact-resistant white woven surface, ideal for high activity level areas such as schools and sports facilities
Order Sample
Back

Case studies featuring Rockfon® Samson™

Complex of primary school and kindergarten,Poland,Wysoka,1.0000 m²,Monika Robaszko-Kowalska,Biuro Achitektoniczne Metropolis,Bartosz Makowski,ROCKFON Samson,1200x600,white

Project: Complex of primary school and kindergarten
Edge and dimension: 1200 x 600

See full project
NO, Brynseng skole, HRTB Arkitekter AS MNAL, School, Rockfon Samson, A edge, 1200x600, white, Chicago Metallic T24 Click 2890

Project: Brynseng School
Edge and dimension: 1200 x 600

See full project
NO, Brynseng skole, HRTB Arkitekter AS MNAL, School, Rockfon Samson, A edge, 1200x600, white, Chicago Metallic T24 Click 2890

Project: Brynseng School
Edge and dimension: 1200 x 600

See full project
NO, Brynseng skole, HRTB Arkitekter AS MNAL, School, Rockfon Samson, A edge, 1200x600, white, Chicago Metallic T24 Click 2890

Project: Brynseng School
Edge and dimension: 1200 x 600

See full project
Back

Sound absorption details

Edge Thickness (mm) Suspension height (mm) αw NRC Sound absorption class (ISO) Sound curve
A24 edge icon 40 225 1.00 1.05 A
Sound curve
A24 edge icon 40 40 0.85 0.90 B
Sound curve
AEX edge icon 40 225 1.00 1.05 A
Sound curve

Sound absorption is measured in accordance with ISO 354.

Sound absorption data αp, αw and absorption class are calculated in accordance with ISO 11654. Sound absorption properties of islands and baffles are quantified by the equivalent sound absorption area Aeq expressed as m² per item.

Back
Sound curve
Back
Sound curve
Back
Sound curve

Other performances

Compare
Reaction To Fire Reaction To Fire A1 (EN 13501-1)
Reaction to fire is classified in accordance with EN 13501-1.
Fire Resistance Fire Resistance The fire resistant properties of stone wool ensure Rockfon ceiling tiles provide fire protection in construction. The fire protection properties of Rockfon ceilings have been tested and classified in accordance with European norm EN 13501-2 and/or national norms depending on requirements in national building codes.
Some sizes and edge details of Rockfon Samson can be used with various Chicago Metallic grids and Rockfon systems to create a 60 minutes fire protecting ceiling in accordance with BS 476 Part 21 and Part 23. They can also be used to create a 30 minutes fire protecting membrane ceiling (integrity only) in accordance with BS 476 Part 22.
The stone wool core of ROCKFON products is non-combustible with a melting point of more than 1000°C and provides fire protection. Some ROCKFON ceilings have been tested and classified in accordance with European norm EN 13501-2 and/or national norms.
Light reflection and light diffusion Light reflection and light diffusion 72%
Light reflection expressed in % is measured in accordance with ISO 7724-2.
Humidity And Sag Resistance Humidity And Sag Resistance Up to 100% RH.
No visible deflection in high humidity
ROCKFON ceiling tiles are dimensionally stable even at humidity levels of up to 100% relative humidity and can be installed at all temperatures ranging from 0°C to 40°C. They can be installed during the very early stage of the build (when windows are not fully sealed). Their lightweight yet stable non-hygroscopic character minimises the final weight of the fully-installed ceiling. ROCKFON ceiling tiles are predominantly classified as Class 1/C/0N in accordance with EN 13964. Certain module sizes (width above 700mm) are Class 2/C/0N.
Cleaning Cleaning Vacuum
Vacuum:
The surface can be vacuum cleaned with a soft brush attachment.

Damp cloth:
The surface can be cleaned using a damp cloth or sponge with a slightly alkaline detergent (pH between 7 and 9) without alcohol, ammonia or chlorine. This may render the surface slightly shinier, so we recommend cleaning the entire surface evenly.
Hygiene Hygiene Stone wool provides no sustenance to microorganisms
Stone wool provides no sustenance to the following microorganisms tested in accordance with JIS Z 2801:2000 and ASTM C 1338-96:

– Escherichia coli
– Staphylococcus aureus
– Methicillin-resistant staphylococcus aureus (MRSA)
– Stachybotrys chartarum
– Penicillium brevicumpactum
– Alternaria tenuissima
– Aspergillus niger
– Sporobolomyces roseum
– Rhodotorula rubra
Environment Environment Fully recyclable stone wool
Indoor Environment Indoor Environment A selection of Rockfon products have been awarded the Finnish M1 emission classification for building materials and the Danish Indoor Climate Label for low emission products
Impact Resistance Impact Resistance 40 mm: Class 1A (Rockfon System OlympiaPlus A Impact 1A)
40 mm: Class 2A (Rockfon System T24 A Impact 2A/3A)
Tested in accordance with EN13964-Annex D. Impact resistance classifications confirm the system´s capability to withstand incidental or occasional impact.
Directly mounted, Rockfon Samson is not recommended for use in areas which are subjected to continuous high levels of impact.
The woven surface of Rockfon Samson provides enhanced resistance to perforation, tested in accordance with NF P 08-301., EN 13964 annex D
Thermal Insulation Thermal Insulation Thermal conductivity:
λD = 37 mW/mK
The thermal conductivity of products with a thickness ≥ 30mm is measured in accordance with EN 12667 and expressed in mW/mK. Thermal resistance is expressed in m²K/W.
Back
Reaction to fire is classified in accordance with EN 13501-1.
Back
The stone wool core of ROCKFON products is non-combustible with a melting point of more than 1000°C and provides fire protection. Some ROCKFON ceilings have been tested and classified in accordance with European norm EN 13501-2 and/or national norms.
Back
Light reflection expressed in % is measured in accordance with ISO 7724-2.
Back
ROCKFON ceiling tiles are dimensionally stable even at humidity levels of up to 100% relative humidity and can be installed at all temperatures ranging from 0°C to 40°C. They can be installed during the very early stage of the build (when windows are not fully sealed). Their lightweight yet stable non-hygroscopic character minimises the final weight of the fully-installed ceiling. ROCKFON ceiling tiles are predominantly classified as Class 1/C/0N in accordance with EN 13964. Certain module sizes (width above 700mm) are Class 2/C/0N.
Back
Vacuum:
The surface can be vacuum cleaned with a soft brush attachment.

Damp cloth:
The surface can be cleaned using a damp cloth or sponge with a slightly alkaline detergent (pH between 7 and 9) without alcohol, ammonia or chlorine. This may render the surface slightly shinier, so we recommend cleaning the entire surface evenly.
Back
Stone wool provides no sustenance to the following microorganisms tested in accordance with JIS Z 2801:2000 and ASTM C 1338-96:

– Escherichia coli
– Staphylococcus aureus
– Methicillin-resistant staphylococcus aureus (MRSA)
– Stachybotrys chartarum
– Penicillium brevicumpactum
– Alternaria tenuissima
– Aspergillus niger
– Sporobolomyces roseum
– Rhodotorula rubra
Back
Back
Back
Back
The thermal conductivity of products with a thickness ≥ 30mm is measured in accordance with EN 12667 and expressed in mW/mK. Thermal resistance is expressed in m²K/W.
Back

Configure your product

This product has 6 variants in different sizes.

01 Edge

02 Size

03 Details

A24

product image

A24-edge tiles are a cost-effective solution that provides easy access to the installations hidden behind the ceiling. Tiles with an A-edge are also the perfect complement to concealed and semi-concealed ceilings (e.g. when used as a perimeter trim). They can be mounted in T24 grid systems. A-edge tiles are demountable.

illustration
Visible grid
Select length and width (mm)
Select thickness (mm)
Edge
Dimensions
Thickness

Full range

Edge Dimensions (mm) Thickness (mm) Weight (Kg/m2) Min. suspension height (mm) Recommended installation system
A24 1200 x 1200 40 4.10 50 Rockfon® System T24 A™
Rockfon® System T24 A, E ECR™

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

αw 1.00
NRC 1.05
Sound absorption class A
Sound curve
Sound curve

Tile details

Minimum installation height 50 mm

Packaging

Pieces Per Pack 5
Area Per Pack 7.20 m2
A24 1200 x 600 40 4.10 50 Rockfon® System T24 A™
Rockfon® System T24 A, E ECR™

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

αw 1.00
NRC 1.05
Sound absorption class A
Sound curve
Sound curve

Tile details

Minimum installation height 50 mm

Packaging

Pieces Per Pack 10
Area Per Pack 7.20 m2
A24 1800 x 600 40 4.10 50 Rockfon® System T24 A™
Rockfon® System T24 A, E ECR™

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

αw 1.00
NRC 1.05
Sound absorption class A
Sound curve
Sound curve

Tile details

Minimum installation height 50 mm

Packaging

Pieces Per Pack 10
Area Per Pack 10.80 m2
A24 2400 x 600 40 4.10 50 Rockfon® System T24 A™
Rockfon® System T24 A, E ECR™

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

αw 1.00
NRC 1.05
Sound absorption class A
Sound curve
Sound curve

Tile details

Minimum installation height 50 mm

Packaging

Pieces Per Pack 10
Area Per Pack 14.40 m2
A24 600 x 600 40 4.10 50 Rockfon® System T24 A™
Rockfon® System T24 A, E ECR™

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

αw 1.00
NRC 1.05
Sound absorption class A
Sound curve
Sound curve

Tile details

Minimum installation height 50 mm

Packaging

Pieces Per Pack 20
Area Per Pack 7.20 m2
AEX 1166 x 1166 40 4.10 180 Rockfon® System Olympia Plus A Impact 1A™

Recommended installation system

Ceiling systems for special applications Rockfon® System Olympia Plus A Impact 1A™ Ideal combination of good acoustics and impact resistance for sports halls

Sound absorption details

αw 1.00
NRC 1.05
Sound absorption class A
Sound curve
Sound curve

Tile details

Minimum installation height 180 mm

Packaging

Pieces Per Pack 10
Area Per Pack 13.60 m2

MS = Minimum Suspension

Back

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

Sound curve
Sound curve

Tile details

Minimum installation height 50 mm
Easy access -

Packaging

Pieces Per Pack 5
Area Per Pack 7.2 m2
Back

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

Sound curve
Sound curve

Tile details

Minimum installation height 50 mm
Easy access -

Packaging

Pieces Per Pack 10
Area Per Pack 7.2 m2
Back

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

Sound curve
Sound curve

Tile details

Minimum installation height 50 mm
Easy access -

Packaging

Pieces Per Pack 10
Area Per Pack 10.8 m2
Back

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

Sound curve
Sound curve

Tile details

Minimum installation height 50 mm
Easy access -

Packaging

Pieces Per Pack 10
Area Per Pack 14.4 m2
Back

Recommended installation system

Visible grid ceiling system Rockfon® System T24 A™ Ceiling system with a 24 mm wide visible grid with A edge tiles
Ceiling systems for special applications Rockfon® System T24 A, E ECR™ Versatile and simple ceiling system suitable for humid and harsh indoor environments such as swimming pools, kitchens and sanitary areas

Sound absorption details

Sound curve
Sound curve

Tile details

Minimum installation height 50 mm
Easy access -

Packaging

Pieces Per Pack 20
Area Per Pack 7.2 m2
Back

Recommended installation system

Ceiling systems for special applications Rockfon® System Olympia Plus A Impact 1A™ Ideal combination of good acoustics and impact resistance for sports halls

Sound absorption details

Sound curve
Sound curve

Tile details

Minimum installation height 180 mm
Easy access -

Packaging

Pieces Per Pack 10
Area Per Pack 13.6 m2
